Saacke ESV 12 ELECTROMAGNETIC VALVE 32 173 50 C 13

Description

The Saacke ESV 12 (specifically with 32 173 50 E 20 / 32 173 50 C 13 rectifier) is a high-performance electromagnetic valve designed for industrial burners, often used for heavy oil (Heizöl). It is characterized by a 230V AC input, 102V DC holding voltage (via rectifier), 100% duty cycle, and IP65 protection, suitable for temperatures up to \(140^{\circ}\text{C}\)

• Model: SAACKE ESV 12 (Electromagnetic/Magnetic Valve).
• Rectifier/Coil Component: 32 173 50 E 20 / 32 173 50 C 13 (Direct Current Coil).
• Operating Voltage (\(U_{N}\)): 230 V, 40–60 Hz (via rectifier 3217350 E 20).
• Holding Voltage (\(U_{DC}\)): 102V DC.
• Current/Power: Anzug-/Haltstrom (Start/Holding current) \(I = 0.52/0.25\text{A}\).
• Duty Cycle: \(100\% \text{ ED}\) (Continuous Operation).
• Pressure Rating (\(P_{B}\)): Max 5 bar.
• Medium Temp: Max \(140^{\circ}\text{C}\).
• Protection: IP65.
• Application: Primarily fuel oil systems (Heizöl DIN 51603).
• Maintenance Note: It is recommended to mount a dirt trap (max mesh size \(0.5\text{ mm}\)) to comply with DIN EN 264.
