Description
The Raytheon Anschütz (Nieaf Smitt) SCB-RAI 10 Signal Calibration Box is a marine-grade unit designed to receive, calibrate, and convert rudder angle sensor signals for up to 10 analog indicators and one NMEA 0183 output. It ensures accurate rudder position display by allowing for individual calibration of indicators, featuring 35mm rail mounting, a USB port for PC-based configuration, and compatibility with various feedback units.
Key Features and Technical Details:
- Function: Corrects rudder angle signals to eliminate mechanical and electrical errors,, with an initial factory accuracy of 1.0% and a calibrated accuracy of less than 0.5%.
- Inputs: Capable of handling voltage (V), current (mA), and potentiometer input signals from feedback units.
- Outputs: Features 10 independent analog indicator outputs and one NMEA 0183 compatible output.
- Configuration: Uses Windows-based software via USB for setup and calibration.
- Mounting: Designed for 35 mm rail mounting.
- Compliance: Compliant with standards such as EN 60945 (marine navigation and radio equipment) and ISO 20673.
- Versions: Available as SCB-RAI 10 (Vers. 1.x) or SCB-RAI 10 E01 (Vers. 2.x).
The SCB-RAI 10 is integral to the Raytheon Anschütz rudder angle indication system, often used in conjunction with units like the 101-532 or 101-529 feedback units and various Nautosteer-compatible indicators.
